Spiral Conveyer

Product introduction

Working Principle:

Spiral blade tums through mechanical transmission, rotating spiral blade promotes materials to go forward, spiral conveyer is divided into pipe spiral conveyer and U type spiral conveyer in the shape customers can choose the appropriate style according 10 the actual needs. The whole of the equipment is made of 304 stainless steel, and can also use other material according to customer requirements. The Equipment can move freely and transport material at any place. The Equipment has good sealing and has no dust leakage. The equipment can be connected with the supporting equipment directly and does not need foundation,so can makes full use of the workshop space.

Superfine powder pulverizer grinding machines

Technical parameter

Model	Feeding pipe diameter (MM)	Motor power (KW)	Axis diameter (MM)	Capacity (KG/H)	Weight (KG)	Feeding height (MM)
Model	Feeding pipe diameter (MM)	Motor power (KW)	Axis diameter (MM)	Capacity (KG/H)	Weight (KG)	Feeding height (MM)
LS-108	108	0.75	68	100-200	Customized	Customized
LS-133	133	1.1	76	200-500
LS-141	141	1.5	76	500-1000
LS-159	159	2.2	76	1000-1500
LS-168	168	2.2	76	1500-2000
LS-219	219	3	76	2000-3000

Product application

This machine is widely used in the transmission of powder and granular materials in the industries of pharmaceutic,chemical.plastic and foodstuff,. etc.The spiral conveyer can be used together with our company's crusher, mixer, granulating machine and other equipments,The machine realizes automatic feeding function,reduces labor costs, and optimizes process.
