Food Universal Coarse Crusher for cereal milling

Product introduction

This machine is applied as supporting equipment, before fine crushing process in such trade as pharmaceutical, chemical and foodstuff etc., which has better crushing effect for any material without limitation on its viscosity, hardness, softness and fiber etc..The machine is applied by the industries of pharmaceutics,chemical and foodstuff,served as the pretreatment coordinated machine for fine grinding process.The machine can process any material without being limited by the viscosity,hardness,softness or fiber shape of the said materials.

Advantages:

01Material,usually all material use stainless steel 304,if you want stainless steel 316,we can make for you.

02Automatic operating :just press button,Easy to clean,usually use water cooling and air compressor is ok .

03Final granules size range from 0.5-20mm.

Working Principle:

This machine is of vertical crushing structure, and the material is fed into the crushing chamber through a hopper, crushed by simultaneous cutting of both fixed and movable knives and rotating impact of rotating knife, and flows to the exit automatically under the effect of rotating centrifugal force. its designed according to GMP standard and wholly made of stainless steel, making the medicine and food met the national hygienic requirement.

Technical parameter

MODEL	CAPACITY KG/H	SPINDLE SPEED R/MIN	FEEDING SIZE MM	FINENESS OF PRODUCT MESH	POWER KW	WEIGHT KG	DIMENTION MM
MODEL	CAPACITY KG/H	SPINDLE SPEED R/MIN	FEEDING SIZE MM	FINENESS OF PRODUCT MESH	POWER KW	WEIGHT KG	DIMENTION MM
JY100	15-100	500	<50	0.5-20	2.2	170	5503801000
JY200	30-300	500	<50	0.5-20	3	220	6004001000
JY300	50-500	500	<100	0.5-20	4	300	7005001100
JY400	100-800	500	<150	0.5-20	5.5	380	8007801300
JY500	150-1000	500	<200	0.5-20	7.5	490	8504801450
JY600	200-1500	500	<250	0.5-20	11	660	9209001600
JY800	300-2000	500	<250	0.5-20	15	850	115010501600

Product application

The machine is applied by the industries of pharmaceutics,chemical and foodstuff,served as the pretreatment coordinated machine for fine grinding process.The machine can process any material without being limited by the viscosity,hardness,softness or fiber shape of the said materials.
